HRB NN3022K/P4 W33 Double Row Full Complement Cylindrical Roller Bearing 3282122 Bearing

Brand Name : HRB

Model Number : NN3022K/P4 W33(3282122)

Certification : ISO9001:2008

Place of Origin : China

MOQ : 1 pcs

Price : negotiation

Payment Terms : T/T or western Union or PayPal

Supply Ability : 3,000pcs per month

Delivery Time : 3 working days after received your payment

Packaging Details : Packed in carton firstly,and then reinforced with wooden case for outer packing

Structure : Cylindrical

Type : Roller

Material : Chrome steel

Application : Vibration machinary,CNC machine and so on

Cage : Brass cage

Contact Now

HRB NN3022K/P4 W33 Double Row Full Complement Cylindrical Roller Bearing 3282122 Bearing

Bearing name :bearing for CNC machine cylindrical roller bearing

Model : NN3022K/P4 W33

Size : 130*182*52 mm

Weight : 5.88 KG

Material : GCR-15

Precision : P5

Quality : ISO9001:2008 approved

OEM service: Offer

Types of cylindrical roller bearing:

.Single row cylindrical roller bearing: NU, NJ, NUP, NUB series

.Double row cylindrical roller bearings:NNU series

.Four row cylindrical roller bearing:FC series

.Single row full complement cylindrical roller bearing:SL18 series, SL 19 series

.Double row full complement cylindrical roller bearing

.SL01 series, SL02 series, SL18 series.

Bearing type	Cage symbol	Specification	Available size
NN	MB	Roller guided machined brass cage	NN3005,NN3026-NN3040 NN3920-NN3956,NN4920-NN4940
NN	TB	Roller guided PPS resin cage	NN3006-NN3024
NNU	MB	Roller guided machined brass cage	NNU4920-NNU4940
N	MR	Roller guided machined brass cage	N1006-N1028
N	TP	Outer ring guided PEEK resin cage	N1009-N1017

Import NSK precision spindle Cylindrical roller bearing NN3022K/P4W33 design draft :

HRB NN3022K/P4 W33 Double Row Full Complement Cylindrical Roller Bearing 3282122 Bearing

Cylindrical roller bearings NN3022K/P4W33

Bearing number : NN3022K/P4W33

Size (mm) : 110x170x45

Brand : NSK

Bore Diameter (mm) : 130

Outer Diameter (mm) : 182

Width (mm) : 52

Bearing dimensions and specification in brand catalogue :

d - 110 mm

D - 170 mm

E - 45 mm

B - 45 mm

C - 45 mm

r min. - 2 mm

Weight - 3.41 Kg

Basic dynamic load rating (C) - 260 kN

Basic static load rating (C0) - 360 kN

(Grease) Lubrication Speed - 6000 r/min

(Oil) Lubrication Speed - 5 500 r/min

Dimension (mm)						Weight (kg)	Rated load ( KN)		Limiting speed (r/min)		Type
d	D	B	r min	F	E	Weight (kg)	Cr	Cor	Grease	oil	Type
100	140	40	1.1	113	137	1.88	125	244	4300	5100	NNU4920
100	150	37	1.5	--	137	1.88	146	245	4000	4800	NN3020
105	145	40	1.1	118	146	1.96	132	270	4100	4800	NNU4921
105	160	41	2	--	146	2.96	192	310	3800	4100	NN3021
110	150	40	1.1	123	155	2.04	132	258	3900	4600	NNU4922
110	170	45	2	--	155	3.76	226	365	3600	4300	NN3022
120	165	45	1.1	134.5	165	2.76	170	328	3600	4200	NNU4924
	200	80	1.112	141		11	--	--	--	--	NNU4124
	180	46	2	--		4.1	232	390	3300	3900	NN3024
130	180	50	1.5	146	182	3.79	187	368	3300	3900	NNU4926
130	200	52	2	--	182	6.04	284	475	3100	3600	NN3026

Bearing photos:

HRB NN3022K/P4 W33 Double Row Full Complement Cylindrical Roller Bearing 3282122 Bearing
