P4 Precision NU6/22E Cylindrical Roller Bearing Full Complement

Product Categories

Wuxi Guangqiang Bearing Trade Co.,Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

P4 Precision NU6/22E Cylindrical Roller Bearing Full Complement

Brand Name : NRB

Model Number : NU6/22E

Certification : ISO9001:2008

Place of Origin : China

MOQ : 1 pcs

Price : negotiation

Payment Terms : T/T or western Union or PayPal

Supply Ability : 3,000pcs per month

Delivery Time : 3 working days after received your payment

Packaging Details : Packed in carton firstly,and then reinforced with wooden case for outer packing

Structure : Cylindrical

Type : Roller

Material : Chrome steel

Application : Vibration machinary,CNC machine and so on

weight : 0.3 kg

Cage : Brass cage

Contact Now

Gcr15 steel Material NRB NU6/22E Single Row Cylindrical Roller Bearing

Bearing name :cylindrical roller bearing

Model : NU6/22E

Size : 22*52*20 mm

Weight : 0.1 KG

Material : GCR-15

Precision : P4

Quality : ISO9001:2008 approved

OEM service: Offer

Types of cylindrical roller bearing:

. Single row cylindrical roller bearing: NU, NJ, NUP, NUB series

. Double row cylindrical roller bearings:NNU series

. Four row cylindrical roller bearing:FC series

. Single row full complement cylindrical roller bearing:SL18 series, SL 19 series

. Double row full complement cylindrical roller bearing

. SL01 series, SL02 series, SL18 series.

Bearing type	Cage symbol	Specification	Available size
NN	MB	Roller guided machined brass cage	NN3005,NN3026-NN3040 NN3920-NN3956,NN4920-NN4940
NN	TB	Roller guided PPS resin cage	NN3006-NN3024
NNU	MB	Roller guided machined brass cage	NNU4920-NNU4940
N	MR	Roller guided machined brass cage	N1006-N1028
N	TP	Outer ring guided PEEK resin cage	N1009-N1017

Import precision spindle Cylindrical roller bearing NU6/22E design draft :

P4 Precision NU6/22E Cylindrical Roller Bearing Full Complement

Cylindrical roller bearings NU6/22E

Bearing number : NU6/22E

Size (mm) : 22x52x20

Brand :NRB

Bore Diameter (mm) : 22

Outer Diameter (mm) :52

Width (mm) :20

Bearing dimensions and specification in brand catalogue :

d - 22 mm

D - 52 mm

B - 20 mm

C - 20 mm

Weight - 0.1 Kg

P4 Precision NU6/22E Cylindrical Roller Bearing Full Complement

Dimension (mm)						Weight (kg)	Rated load ( KN)		Limiting speed (r/min)		Type
d	D	B	r min	F	E	Weight (kg)	Cr	Cor	Grease	oil	Type
100	140	40	1.1	113	137	1.88	125	244	4300	5100	NNU4920
100	150	37	1.5	--	137	1.88	146	245	4000	4800	NN3020
105	145	40	1.1	118	146	1.96	132	270	4100	4800	NNU4921
105	160	41	2	--	146	2.96	192	310	3800	4100	NN3021
110	150	40	1.1	123	155	2.04	132	258	3900	4600	NNU4922
110	170	45	2	--	155	3.76	226	365	3600	4300	NN3022
120	165	45	1.1	134.5	165	2.76	170	328	3600	4200	NNU4924
	200	80	1.112	141		11	--	--	--	--	NNU4124
	180	46	2	--		4.1	232	390	3300	3900	NN3024
130	180	50	1.5	146	182	3.79	187	368	3300	3900	NNU4926
130	200	52	2	--	182	6.04	284	475	3100	3600	NN3026

If you want to buy NU6/22E roller bearing,just contact us.

Product Tags:

NU6/22E Cylindrical Roller Bearing

Vibration Machinary Cylindrical Roller Bearing

P4 Precision Cylindrical Roller Bearing

P4 Precision NU6/22E Cylindrical Roller Bearing Full Complement Images
