0.524 KG Mass Cylindrical Miniature Roller Bearings Less vibration NU2209ECP

  • 1
  • 2

Brand Name : KOYO

Model Number : NU205

Certification : ISO 9001

MOQ : 1

Price : 1 USD

Payment Terms : T/T, Western Union

Supply Ability : 10000 PCS / Month

Delivery Time : 5 working days

Packaging Details : Single packing + standard export packing

Material : GCr15

Precision : P0/P6/P5/P4/P2

Bearing type : Cylindrical Roller Bearing

Cage : Steel

Number of row : Single / double

Clearance : C0 / C3/C4

Contact Now

0.524 KG Mass Cylindrical Miniature Roller Bearings Less vibration NU2209ECP

1. Cylindrical Roller Bearing Specification:

Bearing model NU2209ECP
Material Gcr15
Type Cylindrical Roller Bearing
Size (mm) 45*85*23
Basic dynamic load rating 85 KN
Basic static load rating 81.5 KN
Fatigue load limit 10.6 KN
Mass (KG ) 0.524 KG



2. Description:
1. High precision
2. Low noise
3. Less vibration
4. Be customized
5. Long service life

3 . Cylindrical roller bearing

Can adapt to the position changes between the shaft and housing caused by the thermal expansion or
The mounting error and are most suitable for free end shafts. NJ and NF types can accept certain axial
Load in one direction, and NH and NUP types can accept certain axial load in two directions. Inner ring
And outer ring can be separable, and be they are convenient to mount and dismount.

4 . Cylindrical Roller Bearing Application:

Mainly used for various types of motors, generators, gas turbines, machine tool spindles, deceleration devices, handling handling machinery, four-row cylindrical roller bearing is mainly used in the rolling mill.


3. Our other bearing in stock .

NUMBER SIZE LOAD RATING WEIGHT
d D T DYNAMIC STATIC
30202 15 35 11.75 11900 13500 0.053
30203 17 40 13.25 20000 20200 0.082
30204 20 47 15.25 28300 29200 0.128
30205 25 52 16.25 31600 34400 0.14
30206 30 62 17.25 40500 43800 0.23
30207 35 72 18.25 53400 59200 0.32
30208 40 80 19.75 59900 65400 0.41
30209 45 85 20.75 64800 74700 0.46
30210 50 90 21.75 73600 87500 0.52
30211 55 100 22.75 94900 114000 0.68
30212 60 110 23.75 99100 117000 0.87
30213 65 120 24.75 12100 146000 1.1
30214 70 125 26.25 128000 157000 1.28
30215 75 130 27.25 141000 179000 1.33
30216 80 140 28.25 151000 187000 1.59
30217 85 150 30.5 184000 235000 2.02
30218 90 160 32.5 197000 250000 2.49
30219 95 170 34.5 218000 276000 2.95
30220 100 180 37 278000 375000 3.77
30221 105 190 39 309000 419000 4.48
30222 110 200 41 314000 445000 5.21
30224 120 215 43.5 335000 487000 6.19
30226 130 230 43.75 364000 525000 6.94
30228 140 250 45.75 407000 589000 8.75
30302 15 42 14.25 24400 22500 0.1
30303 17 47 15.25 30300 28400 0.13
30304 20 52 16.25 35600 34500 0.17
30305 25 62 18.25 50200 50100 0.26
30306 30 72 20.75 59500 60600 0.38



0.524 KG Mass Cylindrical Miniature Roller Bearings Less vibration NU2209ECP
0.524 KG Mass Cylindrical Miniature Roller Bearings Less vibration NU2209ECP
