Automobile Stainless Thrust Bearing , Oil Lubrication Cylindrical Thrust Bearing

1. Cylindrical Roller Bearing Specification :

2. Cylindrical Roller Bearing ​:

We can supply many kinds of cylindrical roller bearings.
Single row: N, NU, NJ, NF, NUP, NCF and NJG
Double row: NNU, NN, NNC, NNCF and NNCL.
Four rows:SL series

3 . Cylindrical Roller Bearing Features :

N: The inner ring has two integral flanges and the outer ring is without flanges. Axial displacement of the shaft with respect to the housing can be accommodated in both directions within the bearing itself. Pressed steel and machined brass cages and allowed.

NU: The outer ring has two integral flanges and the inner ring is without flanges. Axial displacement of the shaft with respect to the housing can be accommodated in both directions within the bearing itself. Pressed steel and the machined brass cages are allowed.

NJ: The outer ring has two integral flanges and the inner ring has only one integral flange. The bearings are therefore suitable for the axial location of a shaft in one direction. Pressed steel and machined brass cages are allowed.

NF: The inner ring has two integral flanges and the outer ring has only one integral flange. The bearings can locate a shaft axially in one direction. Pressed steel and machined brass cages are allowed.

NUP: The outer ring has two integral flanges and the inner ring has one integral flange with one separating as flange ring. The bearings can be used as locating bearings, i.e. They can provide axial location for a shaft in both directions.

4 . Competitive Advantage:

1. Bearing manufacturer
2. ISO 9000/9001/9004/19011: 2000
3. Produce by customer's needs
4. High speed, low noise
5. Bearing steel
6. The most competitive price

5. APPLICATION:

Motor, petroleum, milling and heavy loading machines, etc.


6 . We also can offer following bearings :

roller thrust bearing

axial thrust bearing
