Insert Bearing RPNA15/28 Aligning Needle Roller Bearing 15x28x12mm
Stock QTY : 165.pcs (More on the way)
Size : 15x28x12mm Weight : 0.03KG
| Bearing Model | PNA 15 / 28 |
| Structure | Aligning Needle Roller Bearing |
| Size (dxDxB) mm | 15x28x12mm |
| d (mm) | 15 |
| D (mm) | 28 |
| B (mm) | 12 |
| Weight /Mass (KG) | 0.04 |
| Contact Person | Tommy |
| SKYPE | gqbearing |
| WhatsApp/ Webchat | +8618261541498 |
| E-mail | |
We currently have 165.pcs of PNA15 / 28 High Load Aligning Needle Roller Bearing In Stock.If you are in need of PNA15/28 Bearing ,just feel free to contact us.We can assure you the best quality; the most competitive prices; the shortest delivery time and the highest quality service.
For more details of PNA 15 / 28 ,please feel free to contact me by WhatsApp or SKYPE or E-mail.
Besides,we also have Various Kinds of other Bearings & Guide Blocks In Stock,just click the " Contact Now "button for Price & other Information.
| Bearing Model | d (mm) | D (mm) | B (mm) |
| PNA12/28 | 12 | 28 | 12 |
| PNA15/32 | 15 | 32 | 16 |
| PNA17/35 | 17 | 35 | 16 |
| PNA20/42 | 20 | 42 | 20 |
| PNA22/44 | 22 | 44 | 20 |
| PNA25/47 | 25 | 47 | 20 |
| PNA30/52 | 30 | 52 | 20 |
| PNA35/55 | 35 | 55 | 20 |
| PNA40/62 | 40 | 62 | 20 |
| RPNA15/28 | 15 | 28 | 12 |
| RPNA18/32 | 18 | 32 | 16 |
| RPNA20/35 | 20 | 35 | 16 |
| RPNA25/42 | 25 | 42 | 20 |
| RPNA28/44 | 28 | 44 | 20 |
| RPNA30/47 | 30 | 47 | 20 |
| RPNA35/52 | 35 | 52 | 20 |
| RPNA40/55 | 40 | 55 | 20 |
| RPNA45/62 | 45 | 62 | 20 |
Aligning needle roller bearings are X-life bearings. These bearings have optimised raceway surfaces. This gives higher load carrying capacity and longer rating life.
Bearings without inner ring have particularly compact radial dimensions. However, they require a shaft raceway that is hardened and ground.
Compensation of Misalignments : Due to the Spherical Outer Ring and the concave support ring, aligning bearings can compensate static misalignments between the shaft and housing of up to 3°.
Sealing : Aligning needle roller bearings are not sealed.
Lubrication : The open bearings can be lubricated with oil or grease.
Operating temperature : The range of possible operating temperatures is from –20 °C to +100 °C,
restricted by the plastic support rings.
Cages : The cages are made from sheet steel.
